Transistor 2SB1342

Transistor 2SB1342

DESCRIPTION
·With TO-220Fa package
·High DC current gain
·Low saturation voltage
·DARLINGTON
APPLICATIONS
·For low frequency power amplifier and
power driver applications
Absolute maximum ratings(Ta=25)
SYMBOL PARAMETER CONDITIONS VALUE UNIT
VCBO Collector-base voltage Open emitter -80 V
VCEO Collector -emitter voltage Open base -80 V
VEBO Emitter-base voltage Open collector -7 V
IC Collector current -4 A
ICM Collector current-peak -6 A
Ta=25 2
PC Collector power dissipation
TC=25 30
W
Tj Junction temperature 150
Tstg Storage temperature -55~150
