Transistor 2SC5803

Transistor 2SC5803

NPN - isc Power Transistor 1500/800v 12amp 70w

VCBO Collector-Base Voltage 1500 V
VCEO Collector-Emitter Voltage 800 V
VEBO Emitter-Base Voltage 6 V
IC Collector Current- Continuous 12 A
ICM Collector Current- Peak 24 A
PC
Collector Power Dissipation
@ TC=25? 70 W
TJ Junction Temperature 150 ?
Tstg Storage Temperature Range -55~150 ?
